PDC160

High accuracy pressure sensor with digital correction

The PDC167 pressure sensor features the latest technological innovations developed by EFE. The all stainless steel thin film pressure sensing element makes it compatible with most industrial fluids, including the most corrosive. The built-in electronics deliver a high level signal 0.5-4.5V. This smart module allows a correction of the sensor’s measurements in pressure and temperature over the compensation range. It is thus endowed with extreme precision: the total error band is ±0.5% for the entire range from -55 to +125°C. This precision does not limit the dynamics of the sensor :the bandwidth of the signal being as standard 1kHz @-3dB. Miniature and robust, the PDC167 is particularly suitable for embedded use combining temperature, vibrations, shocks and where size and mass are at premium.
